DETAILS
Platform
SuperSix EVO
Model Name
SuperSix EVO 4
Model Code
C11602U
FRAMESET
Frame
SuperSix EVO Carbon, integrated cable routing w/ Switchplate, 12x142 Syntace thru-axle, BSA 68mm threaded BB, flat mount disc, integrated seat binder, SmartSense compatible
Fork
SuperSix EVO Carbon, integrated crown race, 12x100mm Syntace thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/4" Delta steerer, 55mm offset (44-54cm), 45mm offset (56-61cm)
Headset
Integrated, 1-1/8" - 1-1/4"
DRIVETRAIN
Rear Derailleur
Shimano 105 7100, 12-speed
Front Derailleur
Shimano 105 7100, braze-on
Shifters
Shimano 105 7100, 12-speed
Chain
Shimano 105 7100, 12-speed
Crank
Shimano 105 7100, 12-speed, 50/34
Rear Cogs
Shimano 105 R7100, 11-36, 12-speed
Bottom Bracket
Shimano BB-RS500, BSA
BRAKES
Brakes
Shimano 105 7170 hydraulic disc, 160/160 RT70 rotors
Brake Levers
Shimano 105 7100 hydraulic disc
WHEELS
Rims
Maddux 3.0, 28h
Spokes
Stainless Steel, 14g
Tire Size
25
Wheel Size
700
Hubs
(F) Formula CL-712, 12x100mm centerlock / (R) Formula RXC-400, 12x142mm centerlock
Tires
Vittoria Zaffiro Pro Slick, 700x25c
COMPONENTS
Handlebar
Vision Trimax Compact
Stem
Cannondale C1 Conceal, Alloy, 31.8, -6°
Grips
Cannondale Bar Tape, 3.5mm
Saddle
Prologo Nago RS STN, Stainless Steel Rails
Seatpost
Cannondale C1 Aero 40 Carbon, 0mm offset (44-48cm), 20mm offset (51-61cm)
CONNECTIVITY
Wheel Sensor
Cannondale Wheel Sensor
