Frame
Slr oclv mountain carbon, isostrut, udh, 80 mm travel
Frame Set
Slr oclv mountain carbon, isostrut, udh, 80 mm travel
Fork
Rockshox sid ultimate, debonair spring, charger race day damper, dual remote lockout, tapered steerer, 44 mm offset, boost110, 15 mm maxle stealth, 110 mm travel
Shock
Trek isostrut, rockshox sidluxe, 2-position remote damper
Max Compatible Fork Travel
120 mm (533 mm axle-to-crown)
Wheel Front
New bontrager kovee pro 30, oclv mountain carbon, tubeless ready, 6-bolt, boost110, 15 mm thru axle, 29"
Wheel Rear
New bontrager kovee pro 30 carbon, tubeless ready, rapid drive 108, 6-bolt, boost148, 12 mm thru axle, 29"
Skewer Rear
Bontrager switch thru axle, removable lever
Tyre Part
Bontrager tlr sealant, 180 ml/6 oz
Max Tyre Size
Frame: 29x2.40", fork: see manufacturer
Battery
Sram etap battery pack (with charger)
Shifter
Sram axs pod ultimate, paired with dropper
Rear Derailleur
Sram x0 eagle axs, t-type
Crank (Size: S, M)
Sram x0 eagle, t-type, dub, 34t ring, 55 mm chain line, 170 mm length
Crank (Size: ML, L, XL)
Sram x0 eagle, t-type, dub, 34t ring, 55 mm chain line, 175 mm length
Bottom Bracket
Sram dub, 92 mm, pressfit
Cassette
Sram eagle xs-1295, t-type, 10-52, 12-speed
Chain
Sram x0 eagle, t-type, 12-speed
Max. Chainring Size
1x: 38t, min 30t
Saddle
Bontrager aeolus elite, austenite rails, 145 mm width
Seatpost (Size: S)
Rockshox reverb axs, 100 mm travel, wireless, 31.6 mm, 340 mm length
Seatpost (Size: M, ML, L, XL)
Rockshox reverb axs, 150 mm travel, wireless, 31.6 mm, 440 mm length
Handlebar/Stem (Integrated) (Size: S, M, ML)
Bontrager rsl integrated handlebar/stem, oclv carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 70 mm length
Handlebar/Stem (Integrated) (Size: L)
Bontrager rsl integrated handlebar/stem, oclv carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 80 mm length
Handlebar/Stem (Integrated) (Size: XL)
Bontrager rsl integrated handlebar/stem, oclv carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 90 mm length
Head Set
Fsa is-2, 1-1/8" top, 1.5" bottom
Brake
Sram level silver 4-piston hydraulic disc
Brake Rotor (Size: S, M, ML, L, XL)
Sram hs2, 6-bolt, 160 mm
Brake Rotor (Size: S, M, ML, L, XL)
Sram hs2, 6-bolt, 180mm
Rotor Size
Max brake rotor sizes - frame: 160mm, fork: see fork manufacturer
Tool
Bontrager switch lever, w/tool
Weight
M - 11.18 kg / 24.65 lbs (with tlr sealant, no tubes)
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
