Frame
100 Series Alpha Aluminium, hub drive system, tapered head tube, internal routing, flat-mount disc, rack and mudguard mounts
Fork
Domane+ carbon, tapered alloy steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle
Skewer Front
Bontrager Switch thru axle, removable lever
Tyre
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32 mm
Max Tyre Size
38mm without mudguards, 32mm with mudguards
Battery
250 Wh, integrated in down tube
Charger
2A, 42V output, 100V–240V AC input
Shifter
Shimano 105 R7120, 12-speed
Front Derailleur
Shimano 105 R7100, 31.8 mm clamp, down swing
Rear Derailleur
Shimano 105 R7100, 36T max cog
Crank
Size: 49 FSA Vero Pro, 50/34, 165 mm length; Size: 52 FSA Vero Pro, 50/34, 170 mm length; Size: 54, 56 FSA Vero Pro, 50/34, 172.5 mm length; Size: 58, 61 FSA Vero Pro, 50/34, 175 mm length
Bottom Bracket
Torque sensor, threaded, 110 mm spindle
Cassette
Shimano 105 7101, 11-34, 12-speed
Chain
Shimano SLX M7100, 12-speed
Max. Chainring Size
2x: 50/34
Saddle
Size: 49, 52 Verse Short Comp, steel rails, 155 mm width; Size: 54, 56, 58, 61 Verse Short Comp, steel rails, 145 mm width
Seatpost
Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length
Handlebar
Size: 49 Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 38 cm width; Size: 52 Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 40 cm width; Size: 54, 56 Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 42 cm width; Size: 58, 61 Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 44 cm width
Handlebar Tape
Bontrager Supertack Perf tape
Head Set
FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Brake Rotor
Shimano RT66, 6-bolt, 160 mm
Rotor Size
Max brake rotor sizes: 160 mm front and rear
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
