Platform
SuperSix EVO SE
Model Name
SuperSix EVO SE 1
Model Code
C17253U
Frame
SuperSix EVO CX Carbon, internal cable routing w/ Switchplate, 12x142mm Speed Release thru-axle, PF30-83 Ai, flat mount disc, integrated seatpost binder
Fork
SuperSix EVO CX Carbon, integrated crown race, 12x100mm Speed Release thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/2" Delta steerer, 55mm offset
Headset
Integrated, 1-1/8" - 1.5"
Rear Derailleur
Shimano GRX 822, Shadow RD+
Front Derailleur
N/A (Braze-on compatible)
Shifters
Shimano GRX 820, 12-speed
Chain
Shimano XT M8100, 12-speed
Crank
HollowGram, PF83a w/ SpideRing, 40T
Rear Cogs
Shimano XT M8100, 10-45T, 12-speed
Bottom Bracket
Cannondale Alloy PressFit30
Brakes
Shimano GRX 820, 160/160mm CL800 rotors
Brake Levers
Shimano GRX 820
Rims
HollowGram G-S 27 Carbon, 700c, 27mm internal width, 21mm deep, 28h, hookless, tubeless compatible
Spokes
DT Swiss Competition Race (Ai Offset Dish - Rear)
Tire Size
38
Wheel Size
700
Hubs
(F) HollowGram, sealed bearing 12x100mm, centerlock / (R) HollowGram 12x142mm w/ DT Swiss 350 internals, centerlock
Tires
WTB Vulpine TCS Light, 700x40c, tubeless ready
Handlebar
Vision Trimax Carbon Aero
Stem
Cannondale C1 Conceal, Alloy, 31.8, -6°
Grips
Cannondale Bar Tape, 3.5mm
Saddle
Prologo Dimension AGX Tirox, Titanium Rails
Seatpost
HollowGram 27 SL, Carbon, 2 bolt clamp, 330mm, 0mm offset (46cm), 15mm offset (51-58cm)
