Sizes
27.5: XS, S 29: M, L, XL, XXL
Colours
Gloss Metallic Blue, Satin Charcoal
Frame
ALUXX-grade aluminium, disc
Fork
SXC32-3 RCL, coil sprung, hydraulic lockout, tapered aluminium steerer, 15x110 thru axle XS & S: 80mm travel (27.5) M-XXL: 100mm travel (29)
Shock
N/A
Handlebar
Giant Connect Trail, 31.8mm XS & S: 690mm (27.5) M-XXL: 780mm (29)
Grips
Giant Sole-O
Stem
Giant Sport, 7-degree rise
Seatpost
Giant Contact Switch Core 2 position dropper post, 30.9mm XS & S: 100mm drop x 350mm (27.5) M-XXL: 120mm drop x 400mm (29)
Saddle
Giant ErgoContact Trail
Pedals
MTB caged
Shifters
Shimano CUES SL-6000, 1x10
Front Derailleur
N/A
Rear Derailleur
Shimano CUES RD-U6000
Brakes
Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm
Brake Levers
Tektro HDC M275
Cassette
Shimano CUES, CS-LG300, 11x48
Chain
KMC X-11
Crankset
ProWheel Charm, 32t (27.5) or 30t (29)
Bottom Bracket
Cartridge
Rims
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Hubs
Alloy, sealed bearing, [F] 15x110 thru axle, [R] 12x142 thru-axle
Spokes
Stainless, 14g
Tyres
Maxxis Rekon 27.5x2.4" or Maxxis Rekon Race 29x2.4", wire bead
Extras
-
Max Tyre Clearance
2.4"
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
