DETAILS
Platform
Moterra Neo
Model Name
Moterra 4
Model Code
C65423U
FRAMESET
Frame
150mm travel, SmartForm C2 Alloy, Cannondale Tuned Suspension, removable downtube battery, internal cable routing, 148x12mm thru-axle, post mount brake, tapered headtube
Fork
RockShox 35 Silver R, 150mm, Solo Air, 15x110mm stealth thru-axle, tapered steerer, 51mm offset
Headset
Integrated Sealed Bearing, Tapered
Rear Shock
RockShox Deluxe Select R, DebonAir
E-SYSTEM
Drive Unit
Shimano EP8
Battery
Shimano BT-E8036, 630Wh
Charger
Shimano Battery Charger 2A
Display
Shimano SC-EM800, Bluetooth enabled
DRIVETRAIN
Rear Derailleur
SRAM SX Eagle
Shifters
SRAM NX Eagle, 12-speed
Chain
SRAM SX Eagle, 12-speed
Crank
FSA E-Bike, 165mm, SRAM Eagle, 34T Steel
Rear Cogs
SRAM PG-1210, SX Eagle, 11-50, 12-speed
BRAKES
Brakes
TRP Slate G4 4 Piston hydraulic disc, 200/200mm rotors
Brake Levers
TRP hydraulic disc
WHEELS
Rims
WTB STX i25 TCS, 32h, tubeless ready
Spokes
Stainless steel, 14g
Tire Size
2.6
Wheel Size
29
Hubs
(F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT400, 12x148mm thru-axle
Tires
Maxxis Rekon, 29x2.6", 60TPI Exo
Front Tire
Maxxis Rekon, 29x2.6", 60TPI Exo
Rear Tire
Maxxis Rekon, 29x2.6", 60TPI Exo
COMPONENTS
Handlebar
Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
Stem
Cannondale 3, 3D Forged 6061 Alloy, 1-1/8", 31.8, 7°
Grips
Fabric Funguy
Saddle
Cannondale Ergo XC
Seatpost
TranzX dropper, internal routing, 31.6, 100mm (S), 120mm (M), 130mm (L-XL)
